6.5KW & 10KW Solar Hybrid Inverter SPD Instruction

WARNING

By utilizing these two inverters , it is mandatory that protective/safety devices (including fuses/breakers) are installed. Protective devices such as SPDs
(surge protective devices) are required for both your solar panel input and AC input to this inverter.

SPDs protect against transient voltage spikes, surges, or electrical disturbances that could permanently damage the inverter. They are required for each PV string at the inputs and for each hot leg at the AC input.

NOTE: Failure to install these protective devices will render any damage or irreversible
fault codes ineligible for warranty coverage.

SURGE PROTECTIVE DEVICES SPECIFICATION REQUIREMENTS

Solar SPD/ Arrestor

AC Input SPD

6.5KW Inverter



500V, 20kA-40kA, Type 2



150V, 20kA-40kA, Type 2
Click to download Specification Sheet

10KW Inverter



600V, 20kA-40kA, Type 2


150V, 20kA-40kA, Type 2
Click to download Specification Sheet

For your safety and for proper operation of your inverter, we strongly recommend engaging a qualified professional for installation and consultation. Proper and safe installation of this inverter requires a thorough understanding of electrical principles, adherence to local building codes, and the use of appropriate installation techniques. Employing a trained professional helps reduce the risk of irreversible faults, as well as potential catastrophic failures.
